Function description:
1. 4 high-level inputs
2. Two-way RCA output
3. Integrated 16.5V/10A regulated power supply ensures the power amplifier in the condition of 8-16V
input voltage full power output
4. Built-in temperature detection to prevent burning due to high temperature
The maximum output power of this amplifier is 4x47w, 4x35w.
10% distortion
1.This amplifier boosts and stabilizes 12v power supply, the set value is
16v when the power supply voltage input is between 9v-16v. This amplifier
outputs a stable 16v voltage to the amplifier chip.
It can be adapted to this power amplifier chip (4x35wunder10% distortion)
Most speakers (horns) sold in the market provide corresponding power
matching
2.This unit uses Toshiba power amplifier chip as power with cmos
Output (altention: Triode output form chips cannot be used
on this platform)
3.This unit supports 4 balanced up level inputs. 4
adjustable simulation inputs and 4 adjustable equalizer amplifier, the range of equalizer
amplifier +12db
