| Speaker System |
3-way 3-speaker System |
| Speaker Type |
Coaxial |
| Peak Input Power |
360W |
| Rated Input Power |
80W |
| Speaker Size |
6"x9" |
| Speaker Cone Design |
Square array pattern |
| Magnet Type |
Ferrit |
| Terminals |
Slide types |
| Installation Capabillity |
Door/Rear Deck |
Speaker/woofer Specifications
| Peak Input Power |
350W |
| RMS power (CEA spec) |
80 W |
| Woofer Cone material |
Injection P.P. Cone |
| Speaker Basket |
Steel |
| Speaker Surround |
High-roll urethane |
| Sensitivity |
90dB/W/m |
| Frequency Response |
63Hz ~ 20000Hz |
| Speaker Impedance |
4Ω |
| Dimensions (W x H x D) |
365.2 x 194 x 104mm |
| Mounting Depth |
78mm |
| Mouting Hole Diameter |
222mm x 150m |
